Features:
- Single outputs, 35V/5A, 18V/10A, 42V/10A, 20V/20A
- Dual or triple outputs
- Independent digital voltage and current meters for each output with 4 digit resolution
- Switchable local or remote sensing
- Constant voltage or constant current operation
- Variable 1.5 — 5.0V auxiliary output at 5A (EX354RT)
- Compact design uses less bench space
- Silent fan-free cooling (not EX202R/EX4210R)
- DC output switches, automatic mode indication
- RS232 or USB controlled models available (35V/5A single)
- Multi-mode dual model 2x(75V/2A) or 75V/4A or 150V/2A
Specifications:
- Voltage: 35 Volts
- Current: 5 Amps
- Power: 175 Watts
- O/Ps: 1
The EX355P is a 35 V, 175 W, 5 A dc power supply from Thurlby Thandar Instruments. The EX355P is a digitally controlled version of the EX355 with an isolated RS-232 interface. It offers a low-cost solution for a basic programmable PSU and will be sufficient for many applications where the sophistication and complexity of GPIB is not needed.
Технические характеристики
| Manufacturer | Thurlby Thandar Instruments |
|---|---|
| Condition | New |
| Current | 5 A |
| Voltage | 35 V |
| Power | 175 W |
