TBZ043R480272-01 | 4.3-inch UART TFT LCD w/ RTP | 480×272 Pixels | The 4.3″ UART LCD with resistive touchscreen provides standard LCM protocol and touch drive. Easy UI and programming to achieve both display and touch. Three Methods to update the UART display, SD Card, USB, and UART port to update. Support remote protocol communication control and update. The material is RoHS-compliant. Screen Diagonal (inch): 4.3 Resolution (pixel): 480×272 Display Type: TN Display Mode: Transmissive Optimal View: 6 O’clock Touch Screen: Resistive Touch PCBA Dimension (mm) (W x H x D): 122×75.2×7.5 LCD Module Dimensions (mm) (W x H x D): 105.5×67.2×4.5 Active Area (mm) (W x H): 95.04×53.85 Luminance (cd/m2): 230 Interface: UART Input Voltage (V): 4.5 ~ 18 Operational Temperature (°C): -10 ~ +60 Storage Temperature (°C): -20 ~ +80
Технические характеристики
CharacteristicsTypeLCD/TFT, resistive touch screenFormat480 x 272Screen size4.3Applicationsindustrial, for medical equipmentOther characteristicsUART, Modbus, smartWidth
122 mm (4.8031 in)
Height
75.2 mm (2.9606 in)
