P/N: 8HS Key Specs
Item
SLEEVE COUPLING INSERT 8HS HYTREL
OEM
TB Woods
OEM #
8HS
Condition
New OEM Original
Returnable
No
Application
Blowers, Compressors, Conveyors, Mixers, Motors, Pumps
Flange Type — Sleeve Couplings
HS
HP Rating @ 100 RPM
7.2 hp
HP Rating @ 1200 RPM
86.25 hp
HP Rating @ 1800 RPM
129.38 hp
HP Rating @ 3600 RPM
247.97 hp
Insert Design — Couplings
Two-Piece Split
Item — Sleeve Coupling Inserts
Sleeve Coupling Insert
Material — Inserts
Hytrel
Max. RPM
4,500 RPM
Operating Temp.
-65 Degrees to 250 Degrees F
Outside Dia.
5.06 in
Rated Torque
4,530 in-lb
Size — Sleeve Couplings
8
Width
2.5 in
