Specifically designed for underwater remotely operated vehicles, Cygnus offers a dedicated ROV mountable thickness gauge (depth rated to 3,000 m (9,843 ft)) with live A-scan and piezo-composite probe. This gauge is versatile and designed to measure metal thickness in the harshest subsea operating conditions – without the need to remove coatings. Ideal for use in civil engineering, marine structures, offshore platforms, Class surveys on offshore installations or units, subsea inspection, repair and maintenance (IRM) of infrastructure and underwater equipment. Cygnus Instruments builds all of its equipment in the UK using only genuine and original parts and components – including Lemo® Connectors. KEY FEATURES OF THE CYGNUS ROV UTM: — A-scan to assist with measurement verification visually — Multiple-Echo and Echo-Echo modes for accurate measurements through coatings (up to 1 mm (0.04 inch)) as specified by Classification Societies — Single-Echo mode for heavily corroded metals with no coating — Use the Auto Single-Echo / Echo-Echo / Multiple-Echo measuring mode for best results or set manually — Supplied with CygLink software to display and process measurements on a computer at the surface — High-performance SD2C probe fitted with a Hard Rexolite Delay line — Easy calibration and measurement settings via CygLink software at the surface — P50 Probe Handler cleverly-designed to self-align with pipes from 50 mm (1.96 inch) diameters to flat surfaces — Manual or automatic gain control.
Технические характеристики
CharacteristicsTypeportableApplicationsmetal, steel, corrosion, for pipesTechnologyultrasonic, A-scanOther characteristicsportable, NDT, multiple-echo, ultra-rugged, echo-to-echo, single echo, for underwater inspection, underwater, subseaMeasuring range
Min.: 4 mm (0.16 in)
Max.: 30 mm (1.18 in)
Measurement accuracy
0.1 mm (0 in)
Weight
3.7 kg (8.2 lb)
Ambient temperature
Min.: -10 °C (14 °F)
Max.: 50 °C (122 °F)
