The LDT-5980 120W High Power Thermoelectric Temperature Controller provides industry leading accuracy and precision for temperature control of laser diodes and other optoelectronic components. The LDT-5980 features a fully programmable digital PID control loop with auto tune feature. Standard features include four-wire voltage and sensor measurements as well as an AC resistance mode to characterize TE modules during development.
Технические характеристики
- TE Current Range -10.00 to +10.00 A
- TE Voltage Range -12 to +12 V
- TE Output Power 120 W
- Temperature Range -50 to 250°C
- TEC Noise/Ripple
- TEC Output 1 h Stability 0.005°C
- TEC Output 24 h Stability 0.005°C
- Connector Type DB25 Female
- Setpoint Resolution 0.001°C
- Computer Interfaces GPIB and RS-232
- Display Range Resistance (10 A) 10 to 600 k
- Display Range Resistance (100 A) 1 to 60 k
