RM 10-40kVA is a high frequency online rack 3:3 / 3:1 UPS. It uses on-line double conversion and advanced DSP digital control technology, resulting in the highest levels of reliability. Scenarios: Small and medium enterprises, branch offices, small data IT/centers. Workstations, networks, automatic control system and other critical loads Summarization This series UPS is a kind of three-in- three -out high frequency online UPS. The products are modularized and adopt the N+X redundancy. It can flexibly increase the number of the UPS modules according to the load capacity which is convenient for flexible allocation and gradually investment. The UPS can solve most of the power supply problems, such as blackout, over-voltage, under-voltage, voltage sudden drop, oscillating of decreasing extent, high voltage pulse, voltage fluctuation, surge, inrush current, harmonic distortion (THD), noise interference, frequency fluctuation, etc.. This UPS can be applied to different applications from computer device, automatic equipment, communication system to industry equipment. Functions and Features ◆3Phase In/3Phase Out UPS It is 3Phase In/3Phase Out high-density UPS system, of which input current is kept in balance. No unbalance problem might occur. ◆Digital Control This series UPS is controlled by Digital Signal Processor(DSP), ehance, it increases reliability, performance, self-protection, self-diagnostics and so on. ◆Modular Design This series UPS adopts modular design concept. The capacities of modules available are 30KVA.
Технические характеристики
CharacteristicsTypedouble-conversionElectrical characteristicsthree-phase, ACApplicationsdata center, network, server, medical, for server rooms, commercialOther characteristicspure sine wave, with LCD display, modular, Eco mode, redundant, CE, over-voltage, ISO, sine wave, centralized, automatic, 19 rack, rack-mount, RoHS, high-frequency, embedded, high-quality, high-densityOutput power kVA
Min.: 30 kVA (40.79 hp)
Max.: 40 kVA (54.38 hp)
Input voltage
Min.: 304 V
Max.: 456 V
380 V, 400 V
Output voltage
Min.: 376.2 V
Max.: 383.8 V
380 V, 400 V, 415 V
Power
Min.: 30,000 W
Max.: 36,000 W
30,000 W
