The Roundtest RA-H5200 roundness/cylindricity measuring system features a rigid base and highly accurate, highly rigid turntable that achieves exceptional manufacturing accuracy of critical components, such as the rotor and stator, in addition to an air-bearing which incorporates a complex aperture that provides superior rigidity and uniform pressure distribution. As a result, the rotational accuracy (radial), which is the heart of the roundness/ cylindricity measuring system, is a world-class (0.02 +3.5H/10000)µm. A high-accuracy Z-axis column achieves ultra-high column straightness, combined with high-accuracy positioning sensors in the X- and Z-axis drive units provides highly precise and repeatable measurement capabilities. Measurement while tracing is possible through a built-in linear scale in the X-axis to maintain contact with the workpiece surface when displacement due to form variation exceeds the measuring range of the sensor.
- Automatic Adjustment Table (A.A.T) provides high-speed centering and leveling automatically, greatly reducing total measurement time
- Spiral-mode measurement function combines table rotation and rectilinear action allows cylindricity and coaxially for other data to be loaded as a continuous data set
- Continuous OD/ID measurement function performs internal and external diameter measurements without the need to change the detector position
- Enhanced detector safety functions, such as accidental touch and collision detection, minimizes damage to both machine and workpieces
- A surface roughness detector, compliant with the relevant International Standards, can be mounted in place of the roundness measuring detector to create a multiple sensor testing system for roundness/cylindricity and surface roughness
| Order No.: | Product Image: | Column Traverse Range: | Column Max Probing Height: | Main Unit Dimensions: | Main Unit Mass: |
|---|
| Order No.: |
|---|
| 211-531A | — | 13.8″ / 350mm | 13.8″ / 350mm | 49.6 x 28.0 x 66.9″/ 1260 x 710 x 1700mm | 1433lbs / 650kg |
| 211-532A | — | 21.7″ / 550mm | 21.7″ / 550mm | 49.6 x 28.0 x 74.8″/ 1260 x 710 x 1900mm | 1477lbs / 670kg |
| 211-531A |
| 211-532A |
Технические характеристики
| Bearing Type: | Air |
|---|---|
| Table Adjustment Method: | Automatic mic heads |
| Rotating Speed: | 10, 2, 4, 6rpm |
| Table Diameter: | 11.8′ / 300mm |
| Table Centering Range (With DAT function): | ± .2′ / ± 5mm |
| Table Leveling Range: | ±1° |
| Max Table Loading: | 176lbs / 80kg |
| Table Max Probing Diameter: | 15.7′ / 400mm |
| Table Max Loading Diameter: | 26.8′ / 680mm |
| Column Traverse Method: | Motorized |
| Column Measuring Speed: | .5, 1, 2mm/s |
| Column Max Probing Depth: | (Over ø1.26) 3.34′ / (Over ø0.27) 1.97′ / (Over ø32) 85mm / (Over ø7) 50mm |
| Radial Traverse Method: | Motorized |
| Radial Traverse Range: | 8.9′ / 225mm |
| Radial Drive Speed (Max): | 50mm/s |
| Radial measuring speed: | .5, 1, 2mm/s |
| Detector Measuring Force: | 10 to 50 mN |
| Detector Stylus Tip: | Carbide ball diameter .06′ / Carbide ball diameter 1.6mm |
| Standard Detector measuring range: | ±4, ±40, ±400μm |
| Follow Detector measuring range: | ±5mm |
| Detector Measuring Direction: | Bi-directional |
| Stylus Angle Adjustment: | ±45° |
| Data Sampling Points: | 14,400/rev |
| Filter Type: | 2CR50, 2CR75, 2CRPC50, 2CRPC75, Gaussian, Off |
| Cut-off value: | 15, 15-150, 15-1500, 15-500, 150, 150-1500, 1500, 50, 50-1500, 50-500, 500, manual setting upr |
| Reference Circle for Evaluation: | LSC, MCC, MIC, MZC |
| Air pressure: | .39 Mpa |
| Vibration Isolator Mass: | 375lbs / 170kg |
