Drawing number 3515-01 Dimension bolting M20x100 Kind of floor bolting 2 x adhesive anchor M16 x 175 Alternativ floor bolting 2 x M20 x 215 Spacing washer to push-in cam see accessories Fine adjusting range 7 mm Maximum adjustment load 150 kN Maximum torque 60 Nm Torque per 10 kN 4 Nm Hexagonal wrench for adjustment 17 mm Height adjustment per adjusting screw turn 0,375 mm Flexibility/rigidity 5000 N/µm Weight of wedge 15,6 kg
Технические характеристики
CharacteristicsApplicationsprecisionOther characteristicsadjustable
