The 8302-V Vacuum Compatible Picomotor™ Actuator has 1.0 inch (25.4 mm) travel, and is an ideal device for motorizing fine-positioning stages and mounts in your optical or mechanical systems. Use it with our opto-mechanical translation stages or your own custom devices. It has better than 30-nm resolution with minimal backlash, and can exert a 5-lb (22-N) force. Moreover, it offers exceptional long-term stability and the ability to hold their position with no power applied. These last two features make the Picomotor unique among motion-control devices and ideal for typical set-and-hold applications. Such applications include precision control of sample holders inside cold and/or vacuum chambers, hands-off adjustment of hard-to-reach mirror mounts (like those in the center of a large setup), or adjustments of optical mounts that are sensitive to forces applied while twisting a knob (for instance optimizing the alignment of a laser cavity or adjusting the pointing of a beam over a long distance).
Технические характеристики
- Travel Range 25.4 mm
- Minimum Incremental Motion
- Maximum Speed 1.2 mm/min
- Axial Load Capacity 22 N
- Mounting 9.5 mm Shank
- Frequency 2 kHz
- Drive Torque 0.018 Nm
- Environment Vacuum
- Rated Life >1×109 steps
- Vacuum Compatibility 10-6 Torr
- Vacuum Wire Material Teflon
- Wire Length 44.5 mm
- Operating Temperature 10-40 C
