P/N: SPU200-50-N5 Key Specs
Item
NATURAL GAS INFRARED HEATER U-TUBE POSITIVE PRESSURE — — 200000 BTU
OEM
Sunstar Heating Products Inc
OEM #
SPU200-50-N5
Condition
New OEM Original
Returnable
No
Btu High
200000
Burner Pressure W.C. Inches
3-1/2
Construction
Cast Iron Burner / Aluminum Reflectors
Duct Size Inches
4
Fuel Type
Natural Gas
Gas Inlet Pressure Max. Water Column Inches
14
Gas Inlet Pressure Min. Water Column Inches
5
Height Inches
6-1/4
Ignition Type
Direct Spark
Length Feet
27-3/4
Limited Warranty Years
1
Manufacturer Part#
SPU200-50-N5
Min. Clearance Combustible At 45 Degree Angle Inch
Front 84, Rear 24, Ceiling 6, Below 106, End 48
Min. Clearance Combustibles At Horizontal Inch
Side 84, Ceiling 6, Below 106, End 48
Min. Mounting Height Feet At 45 Degree Angle
16
Min. Mounting Height Feet At Horizontal
18
Shape
U
Tube Construction
Hot Rolled Steel
Tube Length Feet
50
Type
Positive Pressure
Weight Lbs
206.4
Width Inches
31
