P/N: SLC10100TU Key Specs
Item
Y SPRING CHECK VALVE PVC 1 FNPT
OEM
Hayward
OEM #
SLC10100TU
Condition
New OEM Original
Returnable
No
Application — Valves
General Purpose
Body Material — Valves
PVC
Cap to Inlet Center
4-29/32 in
Connection Type — Check Valves
FNPT x FNPT
Cracking Pressure — Check Valves
2 to 15 psi
Flow — Valves
9 gpm
Flow Design
Single
Hex Size
1-1/2 in
Item — Check Valves
Check Valve
Length
8-31/32 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
140 Degrees F
Max Water Pressure — Valves
150 psi @ 70 Degrees F
Mechanism and Body Design
Y Spring
Min Temperature — Valves
40 Degrees F
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
6-5/64 in
Pipe or Tube Size — Check Valves
1 in
Seal Material — Check Valves
FPM
Seat Material — Check Valves
FPM
Spring Material — Check Valves
Stainless Steel
Width
2 in
