P/N: 9100KDD Key Specs
Item
RADIAL BEARING DOUBLE SHIELD 10MM BORE
OEM
Timken
OEM #
9100KDD
Condition
New OEM Original
Returnable
No
ABEC Tolerance
1
Bearing Material
Steel
Bore Dia.
10 mm
Bore Tolerance
+0/-.008mm
Cage Material
Steel
Dynamic Load Capacity
1,160 lb
Industry Number
9100KDD
Lubrication
Shell Aeroshell 7
Max. RPM
13,889 RPM
Outside Dia.
26 mm
Outside Dia. Tolerance
+0/-.009mm
Seal/Shield Type
Double Shielded
Shield Material
Steel
Single Row/Double Row
Single Row
Static Load Capacity
440 lb
Temp. Range
-60 Degrees to 200 Degrees F
Unmounted Bearing Item
Radial Ball Bearing
Width
8 mm
