| Arbitrary Function Generator |
| Mask and Limit testing |
| Power Solution Package (PWR-BAS THDP0200,TCP0030A,067-1686-xx deskew fixture) |
| Power measurements and analysis |
| Extend record length from to 62.5 Mpoints per Ch |
| Enhanced Instrument Security |
| Aerospace (MIL-STD-1553, ARINC 429) |
| Automotive serial triggering and analysis (CAN, CAN FD, LIN, FlexRay, and CAN symbolic decoding) |
| Automotive Sensor (SENT) |
| Computer (RS-232/422/485/UART) |
| Embedded (I2C, SPI) |
| Ethernet 10BASE-T and 100BASE-TX |
| MIPI I3C (I3C decode and search only) |
| Decode and Search only |
| Power Management (SPMI) |
| Decode and Search only |
| Decode and Search only |
| USB (USB2.0 LS, FS, HS) |
| Spectrum View frequency domain analysis |
| Increase Spectrum View capture bandwidth to 500 MHz |
| Spectrum View RF versus Time Analysis |
| NTSC and PAL and SECAM video triggering |
| 3 Year Warranty for MSO 44 |
| 5 Year Warranty for MSO 44 |
| 3 Year Warranty for MSO 46 |
| 5 Year Warranty for MSO 46 |
| Add 8 Channel Logic probes |
Features:
- Bandwidth: 500 MHz
- FlexChannel inputs: 6
- Real-time: 6.25 GS/s
- 31.25 Mpoints standard (62.5 Mpoints optional upgrade)
- Sample rate (all analog / digital channels)
- Record length (all analog / digital channels)
- Three-year warranty covering all parts and labor on the instrument
- One-year warranty covering all parts and labor on included probes
Accesssories:
- 500 MHz bandwidth models: Four TPP0500B 500 MHz probes
- Installation and safety manual (translated in English, Japanese, Simplified Chinese)
- Embedded Help
- Power cord
- Calibration certificate documenting traceability to National Metrology Institute(s) and ISO9001/ISO17025 quality system registration
Applications:
- embedded systems
- three-phase power electronics
- automotive electronics
- power supply design
- DC-to DC power converters
The Tektronix MSO46 4-BW-500 is a mixed signal oscillioscope with a remarkably innovative pinch-swipe-zoom touchscreen user interface, a high-definition display, and 4 or 6 FlexChannel inputs that let you measure one analog or eight digital signals per channel.
Технические характеристики
| Manufacturer | Tektronix |
|---|---|
| Condition | New |
| Channels | 6 |
| Frequency | 500 MHz |
| Record Length | 31.25 MPts |
| Sampling Rate | 6.25 GS/s |
