The 9062-XZ Gothic-Arch XZ Translation Stage uses stainless-steel construction and thumbscrew locks to offer the ultimate in stability and rigidity. Gothic-arch bearings offer the smooth motion of ball bearings but high stiffness and repeatability over the 12.7 mm XZ travel range. The 40 x 40 mm platform features 8-32 and 1/4-20 mounting holes. The unique gothic profile provides four points of contact (rather than two) so that the load and momentum are more evenly distributed. Side-mounted micrometer clamps minimize the overall footprint. These stages are compatible with our goniometers and rotation stages. NOTE: Actuators are not included with these stages. Please see specifications for recommended actuators.
Технические характеристики
- Axes of Travel X, Z
- Maximum Stage Travel 12.7 mm
- Centered Normal Load Capacity 84 N
- Vertical Axial Load Capacity 26 N
- Roll 10 arc sec
- Yaw 20 arc sec
- Material Stainless Steel
- Bearings Gothic-Arch Bearings
- Platform Size 40 x 40 mm
- Thread Type 2-56, 8-32, and 1/4-20
- Recommended Adjustment Screw 9301
- Recommended Micrometer 9355
- Recommended Piezo Actuator 8301NF
