The SS050-R3N Suprema Stainless Steel Kinematic Optical Mount offers superior performance in a compact footprint. It comes with a rear loading optic face plates for 1/2 inch (12.7 mm) diameter optics. It is fabricated with hardened stainless steel shaped through a metal injection molding process, which results in a cost effective method of achieving performance approaching that of wrought stainless steel. Three 100 TPI precision adjustment screws are included for a ±,5 tip and tilt range as well as translation.. Ideal for OEM applications, the SN050 and mounts incorporate two 2-56 counterbored thru-holes for mounting purposes. In addition, we have incorporated thru-holes sized for standard 1/16th-in dowel pins to enable repeatable system integration and to prevent clocking effects.
Технические характеристики
- Mechanism Kinematic
- Optic Diameter 12.7 mm
- Number of Actuators 3
- Actuator Drive Hex Key
- Actuator Locks No
- Adjustment Screw Thread 100 TPI
- Adjustments z, x, y
- Sensitivity 8.5 arc sec
- Angular Range ±5°
- Optic Loading Rear
- Material Stainless Steel
- Drive Type Allen-Key, non-locking
- Thread Type 2-56 (M2) CLR
- Optical Axis Height 12.7 mm
