The Mitutoyo blade anvil dial gage can measure the thickness of grooves in a wide range of applications. The blade anvil extends into grooves to easily perform measurements that are otherwise extremely difficult to achieve with other indicators or instruments. The contact points are coated with ceramic for durability and corrosion resistance. The grip handle, easy-to-reach lifting lever and spring-loaded spindle allows for quick and easy measurements without sacrificing accuracy.
- Available in Metric and Inch models
- Measures groove thicknesses up to 10mm/.5” in thickness
- White dial face for easier, precise measurement readings
- Anvil and contact point are constructed with ceramic for better corrosion resistance
- Measuring force is 1.4N or less
- Crystal is glare-free with a scratch-resistant coating
- Supplied in a fitted plastic case
| Order No.: | Product Image: | Units: | Range: | Graduation: | Accuracy: | |
|---|
| 7315A | — | Metric | 0-10mm | 0.01mm | ±15µm |
| 7316S |  | Inch | — | 0.001′ | ±0.001′ |
Технические характеристики
| Technology: | Mechanical |
|---|
| Measuring Force: | 1.4 or lessN |
|---|
| Remarks: | Groove thickness |
|---|
| Required Accessories: | — |
|---|
