Mitutoyo offers fixed, manually articulated and motorized CMM probe heads for both manual and CNC Coordinate Measuring Machines. The probe heads support a wide range of probes and styli to take accurate measurements for nearly any type of application.
| Order No.: | Probe Head: | CMM Type: | Mounting Type: | Positioning Type: | Articulating Type: | Indrexing Capability: | Repeatable Positions: | Rack Changer Support: | Probe Sensors Supported: |
|---|
| Order No.: |
|---|
| A-1049-1795 | PH1 | CNC Manual | Shank | Articulating | Manually by Operator | None | No | Yes | TP20, TP200 |
| A-1070-0003 | MIH | CNC Manual | Shank | Articulating | Manually by Operator | 7.5° each axis | Yes | Yes | TP20, TP200 |
| A-1074-0020 | PH6M | CNC | Shank | Fixed | Not Applicable | None | No | Yes | TP20, TP200,TP7, SP25, SP80, SM, ST, QVP |
| A-1332-0002 | MH8 | CNC Manual | Shank | Articulating | Manually by Operator | 41.57″ 1056mm | Yes | Yes | TP20, TP200 |
| A-4099-0100 | MH20i | CNC Manual | Shank | Articulating | Manually by Operator | 15° each axis | Yes | No | TP20 |
| A-5863-4000 | PH10M | CNC | Shank | Articulating | Motorized | 7.5° each axis | Yes | Yes | TP20, TP200,TP7, SP25, SP80, SM, ST, QVP |
| A-5863-5000 | PH10T | CNC | Shank | Articulating | Motorized | 7.5° each axis | Yes | Yes | TP20, TP200,TP7 |
| A-5863-6000 | PH10MQ | CNC | Quill | Articulating | Motorized | 7.5° each axis | Yes | Yes | TP20, TP200,TP7, SP25, SP80, SM, ST, QVP |
