Description
Features:
- Stoppering w/ 3 shelves
- Air Cooled
- Vacuum Pump
Performance Specifications
- Shelf Temperature Control Range (°C): -70 to 60
- Shelf Temperature Control Range Tolerance (°C): ± 0.5
- Lowest Shelf Temperature (°C): -70
- Lowest Condenser Temperature(°C): -85
- Maximum Condenser Capacity (L): 30
- Condenser Surface Area(in2 / cm2): 850 / 5481
- Maximum Ice Condensing Capacity in 24 hours (L): 20
- Maximum Deposition Rate (L/hour): 0.83
- Condenser Pull-Down from 20 °C to -75 °C (minutes): ≤ 10
- Shelf Pull-Down from 25 °C to -40 °C (minutes): ≤ 25
- Number of Compressors: 2
- Compressor Horsepower: 3.5 , 2
- System Refrigerant: R404A, R290/R508B
- Vacuum Time to 100 Millitorr (minutes): ≤ 20
- Vacuum Rate of Rise (mT/hour): ≤ 30
- Volume-Based Leak Rate (mbar·L/sec): ≤ .0019
- Lowest System Vacuum (mT): ≤ 10
- Temperature Uniformity (°C): ± 1.0
