XSTS-C and XWSS-C are all stainless steel spring coupling with single-piece construction. A slit is inserted into a cylindrical material. ● Made of SUS316L superior in corrosion resistance. ● Cleanroom wash/cleanroom packing provided. It is intended for applications that require chemical resistance, such as FPD production equipment and semiconductor devices. ● High flexibility type XSTS-C and short type XWSS-C are available. ● XSTS-C has a plate spring formed by a slit allows eccentricity, angular misalignment, and end-play to be accepted. ● Application FPD manufacturing device / Semiconductor manufacturing device / Offshore instrument Please feel free to contact us for a quotation.
Технические характеристики
CharacteristicsTypeflexible, spiralProduct applicationsfor shafts, for marine applications, for stepper motors, for servo motorsOther characteristicscompact, high-performance, with high torsional flexibilityInstallation systemflangeTorque
Max.: 35 Nm (25.8147 ft.lb)
Min.: 2 Nm (1.4751 ft.lb)
Rotational speed
Max.: 25,000 rpm (157,079.63 rad.min-1)
Min.: 10,000 rpm (62,831.85 rad.min-1)
