Description
The E+H Proservo NMS80 Tank Gauge is designed for high accuracy liquid level measurement in custody transfer and inventory control applications with NMi- and PTB-approvals. It meets the relevant requirements according to OIML R85 and API 3.1B. It fulfills the exact demands of tank inventory management and loss control and is optimized in regards of total cost saving and safe operation.
Технические характеристики
Features
- Measurement for liquid level, interface and density
- Hardware and software developed according to IEC 61508 up to SIL3
- Process connections: Flanges
- Temperature: -328 to 392°F (-200 to 200°C)
- Pressure: 0 to 87 psi (0 to 6 bar)
- Maximum measuring range: 118ft (36m)
- Accuracy: ±0.02in (±0.4mm)
