Description
The E+H Micropilot NMR81 Radar Transmitter is used for custody transfer and inventory control applications with NMi and PTB approvals and meets the requirements according to OIML R85 and API 3.1B. The NMR81 is particularly suited for free space applications up to 70m. The drip-off lens antenna with 80 GHz transmitting frequency produces a sharply focused beam angle of 3° and avoids obstacles even close to tank wall.
Технические характеристики
Features
- Hardware and software developed according to IEC 61508 up to SIL3
- Accuracy up to ±0.5mm (±0.02in)
- 80GHz technology
- Flange process connections
- Temp range: -40 to 338°F (-40 to 170°C)
- Pressure: Vacuum to 232psi (Vacuum to 16bar)
- Maximum measuring range: 230ft (70m)
Common Use: Tank gauging and custody transfer for high-accuracy measurement.
