Description
The E+H Easytemp TSM187 RTD Thermometer range covers a wide variety of market needs worldwide. Typical application can be found in the chemical and pharmaceutical industry, food, water and waste water and power plants. Preferred applications are in vessels or in pipes, where requirements are short response time mechanical strength.
The compact thermometer assembly includes a replaceable insert in mineral insulated cable which is protected by a thermowell with process connection . The terminal head is according to DIN 43729, form B, and is thermally uncoupled by a extension neck. The built-in head transmitter converts the resistance value into a temperature linear 4…20 mA analog output signal.
Технические характеристики
Features
- Various measuring ranges selectable
- 2-wire technology, 4… 20 mA
- High accuracy of sensor and electronics
- Replaceable mineral insulated insert
- Replaceable electronics
