SPRAY CHARACTERISTICS The SDX series nozzles produce a hollow cone spray pattern with uniform particle size distribution even at low operating pressures. Flow rates are certified to be within +15% of rated capacity at 69 Bar.G. and within +5° of rated spray angle when test with water. Unique, patented single inlet, spiral swirl chamber offers increased nozzle life, improved product uniformity, density or solubility. Minimal friction due to nozzle design permitting 10-20% lower operating pressure than conventional slotted distributor nozzle for equivalent atomization quality. Extended pump life due to lower operating pressure. Reduction in fine particles is possible due to lower pressure requirements. CONSTRUCTION AND MATERIALS Eight part construction (see part and material list below). Nozzle bodies, screw pins and adaptors are available in 316 Stainless Steel. Other materials available on special request. Orifice discs are easily removable and are available in Tungsten Carbide, Chrome Carbide and Ceramic as standard. Swirl chambers are standard in Tungsten Carbide, Hardened Stainless Steel or Ceramic. End plates are available in Tungsten Carbide, Chrome Carbide and Ceramic. Combined swirl chamber/end plate is available in Tungsten Carbide only Seals are available in Nylon, PTFE, Copper, Hard Fibre and Aluminium. ORDER EXAMPLE Please indicate all component parts and materials when ordering. Max. Design Pressure: 500 Bar.G. Max. Design Temperature: 540° (Metal Seals), 150° (Other Seals).
Технические характеристики
CharacteristicsFunctionfor dryingStreamhollow-coneMaterialtungsten carbide, ceramic, stainless steelOther characteristicsspiral
