SPRING APPLIED, HYDRAULICALLY RELEASED — TYPE EBS 008 FL BRAKING FORCE UP TO 370,000 N The floating versions of the EBS series are used for applications with limited installation space for a two-modular brake design or where economic interests are paramount. It has a device for air gap allignment to achieve an equal air gap between the brake disc and both of the brake pads. A wide range of applications for these systems are passive holding and emergency stop brakes, which are closed by the spring when not in use. Typical applications for this spring-operated, hydraulically opening brake calliper are cranes, hoists and heavy industry. The floating versions of the EBS series are designed that no significant torgues are inducted into the pedestal construction. They can be used with different brake disc thicknesses by providing a spacer plate between the spring storage module and the floating module. For further information or a non-binding offer, please contact us via our contact form. CAD data will be available on request or from January via our new CADENAS portal.
Технические характеристики
CharacteristicsTypediscOperationspring activated, hydraulic releaseOther characteristicssafety, modular, for heavy-duty applications, for conveyorsBraking force
Max.: 370 kN
Min.: 180 kN
