The EC057C series brushless DC motor is a high torque density model brushless motor in a NEMA 23 configuration. It is offered in 4 motor lengths with continuous torque from 0.078 — 0.28 Nm. Features: Speeds up to 12,000 RPM DC bus voltage up to 76.4 Vdc NEMA 23 configuration Eight standard windings — Special windings available 4 Pole Rare Earth design
Технические характеристики
CharacteristicsAC/DCDCTypebrushlessVoltage 90 VConfigurationNEMA 23Number of poles4-polePower
Max.: 170 W (0.231 hp)
Min.: 46 W (0.063 hp)
Torque
Max.: 0.28 Nm (0.2065 ft.lb)
Min.: 0.079 Nm (0.0583 ft.lb)
Rotational speed
12,000 rpm (75,398.22 rad.min-1)
Diameter
57 mm (2.24 in)
