GENERAL SPECIFICATION Winding type：YWE Hall effect angle：120 Deg. Electrical angle Radial play：0.02mm @460g End play：0.08mm @450g Max. radial force：220N @ 20mm from the flange Max. axial force：60N Insulation class：B Dielectric strength：500VDC for one minute Insulation resistance：100MΩ min., 500VDC
Технические характеристики
CharacteristicsAC/DCthree-phaseTypebrushlessVoltage 48 VNumber of poles4-polePower
785 W, 1,570 W (1.067 hp)
Torque
2.5 Nm, 5 Nm (1.8439 ft.lb)
Rotational speed
3,000 rpm (18,849.56 rad.min-1)
