Sick WLL190T-2P333
Datasheet:
- Article: 6032555
- View: Autonomous operation
- Dimensions (W x H x D): 10.5 mm x 34.8 mm x 76.5 mm
- Housing shape (light output): Rectangular
- Operating distance, max.: 0 m … 4 m, Cross-beam system
- Sensing distance : 0 mm … 480 mm, Object reflection system, 0 … 2 m, Beam intersection system,
- Focus: Approx. 65°
- Emission type: Visible red light
- RADIATION SOURCE: LED
- Emission angle: Approx. 65°
- Wavelength: 650 nm
- Setting: Setting button
- Indication: Display
- Display: LED status indicator/dual 4 -digital digital display, Set value (green indicator) and actual value (red indicator) are displayed simultaneously, parameter indication
- Supply voltage: 10 V DC … 24 V DC
- Residual ripple: ? 10%
- Switching output: PNP
- Switching type: LIGHT/DARK
- Selectable switching type: Manually selected
- Output current Imax: ? 100 mA
- Rating: ? 2 ms, ? 60 µs, ? 250 µs
- Switching frequency: 8.333 Hz, 2.000 Hz, 250 Hz,
- Time function: No time delay, Off delay, On delay, Single signal,
- Delay time: Programmable, 0 ms … 9.999 ms
- Connection type: M8 connector, 3-pin.
- Protection circuits: A, B, C, D,
- Protection class: III
- Weight : 25 g
- Case material: Plastic, ABS/PC
- Protection type: IP66
- Operating temperature range: –25 °C … +55 °C
- Storage temperature range: –40 °C … +70 °C
- Series:WLL190T- 2
- Sensing distance:0 … 480 mm
- Output type: PNP
- Type of radiation: visible red light
