The MIR 3000F — HDmag Flex is an incremental encoder from Baumer, designed for high-precision and reliable position measurement in industrial applications. Utilizing magnetic sensing technology, it features a flexible design, allowing it to accommodate a wide range of shaft diameters.
Datasheet:
- Voltage Supply: 4.75…30 VDC
- Consumption w/o Load: ≤300 mA (24 VDC)
- Initializing Time: ≤1000 ms after power on
- Output Signals: A+, B+, R+, A-, B-, R-
- Sensing Method: Magnetic
- Status Indicator: Color-LED, system OK output
- Interference Immunity: EN 61000-6-2
- Emitted Interference: EN 61000-6-3
- Approval: CE, UL approval / E217823
Electrical Ratings (Square-Wave)
- Pulses per Revolution: 512…131072
- Phase Shift: 90° ±2°
- Duty Cycle: 45…55 %
- Reference Signal: Zero pulse, width 90°
- Output Frequency: ≤500 kHz (HTL), ≤2 MHz (TTL)
- Output Stages: HTL, TTL/RS422
Electrical Ratings (SinCos)
- Sinewave Cycles per Revolution: 512…16384
- Phase Shift: 90° ±2°
- Reference Signal: Zero pulse, width 360°
- Output Frequency: ≤500 kHz
- Output Stages: SinCos 1 Vpp
Mechanical Design
- Dimensions (Sensor Head): 165 x 25 x 93 mm
- Shaft Type: ø300…3185 mm (through hollow shaft)
- Axial Tolerance: ±5 mm (belt to head)
- Radial Tolerance: 1…3 mm (belt to head)
- Protection EN 60529: IP 67
- Operating Speed: ≤1850 rpm (ø300 mm), ≤150 rpm (ø1500 mm)
- Material: Housing sensing head: aluminium alloy; Magnetic belt: stainless steel (1.4310)
- Operating Temperature: -40…+85 °C
- Resistance: IEC 60068-2-6 Vibration 30 g, 10-2000 Hz; IEC 60068-2-27 Shock 300 g, 6 ms
- Weight: Approx. 730 g (head), 120 g (belt/m), 17 g (lock)
- Connection: Flange connector M23, 12-pin
| MIR3000F-0300.MF.000720.A | 11203329 |
| MIR3000F-0300.MF.001024.A | 11128431 |
| MIR3000F-0300.MF.002048.A | 11112825 |
| MIR3000F-0300.MF.004096.A | 11180894 |
| MIR3000F-0300.MF.010000.A | 11242629 |
| MIR3000F-0300.MF.032768.A | 11136816 |
| MIR3000F-0300.MF.131072.A | 11120829 |
| MIR3000F-0300.MQ.000100.A/0050 | 11137114 |
| MIR3000F-0300.MQ.000512.A | 11183753 |
| MIR3000F-0300.MQ.001024.A | 11118032 |
| MIR3000F-0300.MQ.001024.A/9500 | 11147212 |
| MIR3000F-0300.MQ.002048.A | 11110753 |
| MIR3000F-0300.MQ.008192.A | 11143320 |
| MIR3000F-0300.MQ.032768.A | 11152718 |
| MIR3000F-0300.MT.000512.A | 11166575 |
| MIR3000F-0300.MT.000512.A/9500 | 11166577 |
| MIR3000F-0300.MT.016384.A | 11186510 |
| MIR3000F-0308.MF.004096.A | 11148614 |
| MIR3000F-0309.MQ.002048.A | 11128377 |
| MIR3000F-0310.MF.004096.A | 11146128 |
| MIR3000F-0310.MF.040000.A | 11158736 |
| MIR3000F-0310.MQ.002048.A | 11125466 |
| MIR3000F-0310.MQ.016384.A | 11124330 |
| MIR3000F-0311.MQ.001024.A | 11191174 |
| MIR3000F-0315.MQ.001000.A | 11193475 |
| MIR3000F-0315.MQ.004096.A | 11193203 |
| MIR3000F-0316.MF.040000.A | 11158761 |
| MIR3000F-0320.MF.005000.A | 11183825 |
| MIR3000F-0320.MQ.002048.A | 11206100 |
| MIR3000F-0320.MQ.004096.A | 11171200 |
| MIR3000F-0320.MQ.016384.A | 11181315 |
| MIR3000F-0330.MF.001024.A | 11125462 |
| MIR3000F-0330.MQ.001024.A | 11127413 |
| MIR3000F-0340.MF.000720.A | 11176337 |
| MIR3000F-0340.MF.000720.A/9500 | 11193657 |
| MIR3000F-0340.MF.002048.A | 11162133 |
| MIR3000F-0340.MF.005000.A | 11183824 |
| MIR3000F-0348.MF.002048.A | 11183265 |
| MIR3000F-0350.MF.002048.A/9500 | 11161383 |
| MIR3000F-0350.MF.004096.A | 11124478 |
| MIR3000F-0350.MQ.001024.A | 11125243 |
| MIR3000F-0350.MT.001024.A | 11169952 |
| MIR3000F-0355.MQ.001024.A | 11120467 |
| MIR3000F-0360.MT.004096.A | 11141441 |
| MIR3000F-0380.MF.032768.A | 11119706 |
| MIR3000F-0387.MF.002048.A | 11116896 |
| MIR3000F-0390.MF.000720.A | 11125566 |
| MIR3000F-0390.MQ.000512.A | 11154808 |
| MIR3000F-0390.MQ.002048.A/9500 | 11209998 |
| MIR3000F-0400.MF.001024.A | 11124725 |
| MIR3000F-0400.MF.004096.A | 11110756 |
| MIR3000F-0400.MF.008192.A/9500 | 11176710 |
| MIR3000F-0400.MF.032768.A | 11140568 |
| MIR3000F-0400.MQ.001000.A | 11127404 |
| MIR3000F-0400.MT.001024.A | 11189470 |
| MIR3000F-0400.MT.001024.A/9500 | 11189471 |
| MIR3000F-0445.MF.000720.A | 11205879 |
| MIR3000F-0450.MF.000720.A | 11183754 |
| MIR3000F-0450.MF.008192.A | 11215311 |
| MIR3000F-0450.MF.131072.A | 11148828 |
| MIR3000F-0450.MQ.001024.A | 11117213 |
| MIR3000F-0453.MF.131072.A/0050 | 11162697 |
| MIR3000F-0470.MT.004096.A | 11141440 |
| MIR3000F-0480.MF.004096.A/9500 | 11172307 |
| MIR3000F-0480.MF.008192.A | 11225440 |
| MIR3000F-0480.MQ.004096.A | 11124982 |
| MIR3000F-0480.MQ.004096.A/9500 | 11172306 |
| MIR3000F-0495.MF.131072.A | 11122039 |
| MIR3000F-0500.MF.004096.A | 11129672 |
| MIR3000F-0500.MQ.001000.A | 11127103 |
| MIR3000F-0500.MQ.001024.A | 11136947 |
| MIR3000F-0505.MF.004096.A | 11156012 |
| MIR3000F-0530.MT.008192.A | 11141348 |
| MIR3000F-0540.MQ.065536.A | 11126741 |
| MIR3000F-0540.MQ.131072.A | 11126517 |
| MIR3000F-0582.MF.016384.A | 11168167 |
| MIR3000F-0596.MF.131072.A | 11160629 |
| MIR3000F-0596.MF.131072.A/9500 | 11160603 |
| MIR3000F-0600.MQ.000900.A | 11202528 |
| MIR3000F-0600.MQ.032768.A | 11140286 |
| MIR3000F-0630.MQ.001000.A | 11130188 |
| MIR3000F-0650.MQ.000512.A/9500 | 11206483 |
| MIR3000F-0660.MF.010000.A | 11125465 |
| MIR3000F-0690.MF.131072.A | 11178164 |
| MIR3000F-0700.MQ.004096.A | 11140289 |
| MIR3000F-0707.MF.004096.A | 11139598 |
| MIR3000F-0720.MQ.016384.A/9500_9600_++++ | 11135453 |
| MIR3000F-0720.MT.001024.A/9500_9600_++++ | 11135455 |
| MIR3000F-0730.MQ.001024.A | 11114779 |
| MIR3000F-0736.MQ.016384.A/9500 | 11123768 |
| MIR3000F-0736.MQ.016384.A/9500_9600_++++ | 11123897 |
| MIR3000F-0736.MT.001024.A | 11123767 |
| MIR3000F-0736.MT.001024.A/9500 | 11123765 |
| MIR3000F-0736.MT.001024.A/9500_9600_++++ | 11123896 |
| MIR3000F-0737.MQ.004096.A | 11117603 |
| MIR3000F-0800.MQ.004096.A | 11146990 |
| MIR3000F-0830.MQ.001024.A | 11153181 |
| MIR3000F-0850.MQ.001024.A | 11140149 |
| MIR3000F-0870.MQ.001024.A | 11147236 |
| MIR3000F-0888.MQ.001024.A | 11147019 |
| MIR3000F-0900.MF.131072.A/9600_9601 | 11170028 |
| MIR3000F-0900.MQ.001024.A | 11119230 |
| MIR3000F-0914.MT.001024.A | 11110778 |
| MIR3000F-0915.MQ.001024.A | 11123016 |
| MIR3000F-0915.MQ.001024.A/9500 | 11123018 |
| MIR3000F-0915.MT.001024.A | 11123772 |
| MIR3000F-0916.MQ.001024.A | 11117685 |
| MIR3000F-0940.MQ.001024.A | 11153185 |
| MIR3000F-0950.MQ.016384.A/0050 | 11147221 |
| MIR3000F-0960.MQ.001024.A | 11138057 |
| MIR3000F-0980.MQ.001024.A | 11137153 |
| MIR3000F-0980.MQ.008192.A | 11120797 |
| MIR3000F-1000.MF.131072.A | 11137045 |
| MIR3000F-1020.MT.016384.A | 11110757 |
| MIR3000F-1040.MQ.008192.A | 11119037 |
| MIR3000F-1050.MQ.000512.A | 11198108 |
| MIR3000F-1070.MQ.004096.A/9500 | 11147146 |
| MIR3000F-1139.MQ.008192.A | 11116876 |
| MIR3000F-1160.MQ.016384.A/0200 | 11151916 |
| MIR3000F-1200.MT.016384.A | 11126804 |
| MIR3000F-1210.MF.004096.A | 11127416 |
| MIR3000F-1210.MQ.131072.A | 11125873 |
| MIR3000F-1210.MT.016384.A/9500 | 11127593 |
| MIR3000F-1238.MF.131072.A | 11203328 |
| MIR3000F-1240.MF.131072.A | 11203327 |
| MIR3000F-1300.MQ.032768.A | 11183439 |
| MIR3000F-1300.MQ.032768.A/9500 | 11183480 |
| MIR3000F-1325.MF.032768.A | 11120267 |
| MIR3000F-1349.MF.131072.A | 11210779 |
| MIR3000F-1349.MF.131072.A/9500 | 11210821 |
| MIR3000F-1350.MQ.008192.A | 11110777 |
| MIR3000F-1350.MQ.008192.A/0050 | 11116381 |
| MIR3000F-1358.MQ.032768.A | 11142650 |
| MIR3000F-1386.MF.016384.A | 11203388 |
| MIR3000F-1400.MQ.002048.A | 11204324 |
| MIR3000F-1475.MQ.016384.A/0200 | 11135338 |
| MIR3000F-1504.MF.131072.A | 11193654 |
| MIR3000F-1504.MF.131072.A/9500 | 11193656 |
| MIR3000F-1551.MF.032768.A | 11153947 |
| MIR3000F-1640.MQ.008192.A/0050 | 11126048 |
| MIR3000F-1640.MQ.008192.A/0050_9500 | 11122474 |
| MIR3000F-1642.MQ.008192.A/0050 | 11191649 |
| MIR3000F-1690.MQ.000200.A/0050 | 11117038 |
| MIR3000F-1690.MQ.002048.A/0050 | 11122473 |
| MIR3000F-1690.MQ.016384.A/0050 | 11136280 |
| MIR3000F-1690.MQ.016384.A/0200 | 11125907 |
| MIR3000F-1845.MQ.000500.A/0050_9500 | 11200332 |
| MIR3000F-1846.MQ.000500.A/0050_9600_++++ | 11210158 |
| MIR3000F-1900.MF.131072.A | 11158444 |
| MIR3000F-1901.MF.131072.A/0050 | 11158638 |
| MIR3000F-1915.MF.131072.A/0050 | 11172128 |
| MIR3000F-2180.MF.032768.A | 11121737 |
| MIR3000F-2300.MQ.000500.A/0050 | 11117039 |
| MIR3000F-2300.MQ.016384.A/0050 | 11161800 |
| MIR3000F-2302.MQ.000500.A | 11139523 |
| MIR3000F-2302.MQ.000500.A/0001_9600 | 11140778 |
| MIR3000F-2880.MQ.001024.A | 11117214 |
| MIR3000F-2900.MQ.131072.A | 11199190 |
| MIR3000F-3000.MQ.002048.A | 11125231 |
| MIR3000F-3050.MT.016384.A | 11126805 |
| MIR3000F-Dummy im Koffer | 11116853 |
