The QTR 65 is the smallest torque motor in the Tecnotion QTR range. This motor is optimized for small and low voltage applications. The 65 Series is available in four motor ‘heights’ or ‘sizes’, a 17, 25, 34 and 60 size motor. Compact sizing and low voltage support make the 65 mm QTR motor ideal for robotics applications.
Технические характеристики
CharacteristicsAC/DC3-phaseTypesynchronousConfigurationhollow-shaft, compact, frameless, smallNumber of poles8-poleApplicationsfor robotics, for the semiconductor industryOther characteristicsdirect-drive, low-voltagePower
53 W, 99 W, 138 W, 217 W (0.072 hp)
Current
4.86 A, 5.61 A, 8.65 A, 11.07 A
Torque
0.29 Nm, 0.66 Nm, 1.08 Nm, 2.31 Nm (0.2139 ft.lb)
Rotational speed
1,030 rpm, 2,840 rpm, 3,730 rpm, 6,130 rpm (6,471.68 rad.min-1)
Diameter
65 mm (2.56 in)
