Additional Features:
- Protection: Over temperature, Input and Output over current
- Output current limit is adjustable from 0 to maximum available for the model in use
- Harmonic Distortion: 0.5%
- Closed box calibration
- Input: 115 VAC 50/60 Hz
- Voltage Range: 0-130 VAC, 0-260 VAC
- Frequency Range: 47-63 Hz
- Frequency Adjustment Range: 47-500 Hz
North America/Japan Sockets
- 0-130 VAC
- 10A RMS Max
Austria, Finland, Netherlands, Norway, Sweden, West Germany, India, Denmark, Switzerland, and Italy Sockets
- 0-260 VAC
- 220 VAC Nominal
- 5A RMS Max
United Kingdom and Australia Sockets
- 0-260 VAC
- 240 VAC Nominal
- 5A RMS Max
The Interpower 1127 International Power Source provides a low-cost, convenient source of AC power at various operating voltages and frequencies found around the world (typically 110–240VAC/50–60Hz) which is important for testing any products that are exported. Output power is delivered through one of two ranges. Low range (NEMA 5-20) and High range through one of the eight international sockets.
With numerous plug patterns used around the world, engineers and designers need to verify that equipment and consumer electrical products will run safely and reliably on specific voltages and frequencies—before exporting. This makes testing during product development and prior to shipment very important.
Технические характеристики
| Manufacturer | Interpower |
|---|---|
| Condition | Used |
| Phase | 1 |
