The SN100C-F2H-V6 vacuum compatible Suprema Stainless Steel Kinematic Optical Mounts are fabricated from powdered stainless steel and specially prepared for high vacuum environments. The SN100 Clear Edge version comes with removable 100-TPI actuators and has polished and lapped carbide pads which enable smooth, repeatable motion with outstanding stability. These mounts have a two-actuator configuration with locking Hex adjustment screws providing tip and tilt adjustability. Convenient 8-32 (M4) counterbored clearance holes provide quick, precise, secure and stable mounting. Suprema mounts are compatible with standard post and post holder systems for adjustable height and pedestal posts for a stable fixed height.
Технические характеристики
- Mechanism Kinematic
- Optic Diameter 25.4 mm
- Number of Actuators 2
- Actuator Locks Yes
- Adjustment Screw Thread 100 TPI
- Adjustments x, y
- Sensitivity 3.8 arc sec
- Angular Range ±7°
- Optic Loading Front
- Material Stainless Steel
- Drive Type Allen-Key, locking
- Thread Type 8-32 (M4) CLR
- Optical Axis Height 25.4 mm
- Vacuum Compatibility 10-6 Torr
