Vertical Balancing Machines 1.Specially designedsolid brackets can effectively transmit mechanical force 2.Durable and reliable sensor possesses high sensitivity and good linearity 3.Permanent calibration brings high accuracy 4.Special clamp offers higher accuracy and easier operation 5.Advanced electrical measuring system and friendly man-machine interface 6.As the customer’s requestthe de-weighting system can be equiped 7.PHLD series are applicable for clutch pressure plate brake disc brake drum pulley fan saw blade grinding wheel chuck flange etc Technical data at a glance — PHLD-5Q Max Mass of Workpiece (kg) — 5 Max Diameter of Workpiece (mm) — Φ350-500 Height of workpiece(mm) — 120 Spindle speed(r/min) — 1200 Motor power(kw) — 0.373) Min Achievable Residual Unbalance Amount (emar) — 2g · mm/kg 3) Frequency conversion
Технические характеристики
CharacteristicsOrientationverticalTypehard bearingApplicationsfor fans, for brake discs, pulley, for clutch plates, flywheel, torque converter, circular saw blade, for grinding wheelsOther characteristicshigh-accuracy, modular, compactRotational speed
1,200 rpm (7,540 rad.min-1)
Weight on rotor
Min.: 0.5 kg (1.1 lb)
Max.: 5 kg (11 lb)
