Easy Clean Vacuum Pumps, GVEC Series The GVEC series “Easy Clean” vacuum pumps have been designed to meet the needs of vacuum handling applications in industries whose production requires frequent cleaning, particularly in the food-processing sector. Advantages : . Plastic (POM-C) and Inox (316L) conception: meet the requirements of splash zones, are resistant to cleaning agents and corrosion. . Compact and light design: installation as close as possible to suction cups to improve the evacuation times and production rate. .Easy disassembly: quick and precise cleaning Material : . Body and mixer: POM-C . Nozzle: 316L stainless steel . Seal: EPDM . Ø Nozzle : 1.5 , 2.5 , 3 mm . Max. vacuum : 75% . Max. air drawn in: 330 Nl/min . Plastic (POM-C) and Inox (316L) conception
Технические характеристики
CharacteristicsTechnologyVenturiLubricationoil-freeNumber of stagessingle-stageApplicationsfor laboratories, for food, for packaging, for industrial applicationsOther characteristicscompact, high-performance, chemical-resistant, small, pneumatic, anti-corrosionUltimate vacuum
-750 mbar (-10.88 psi)
Flow rate
Min.: 95 l/min (25.1 us gal/min)
Max.: 330 l/min (87.18 us gal/min)
