Features:
- High sine wave purity with low phase noise and jitter, audio band THD down to 0.05%
- Square waves up to 100MHz with variable duty cycle, edge speeds down to 3ns
- Resolution of up to 15 digits or 1µHz, high stability TCXO timebase
- Two identical channels — independent or linked with coupled and tracking modes
- Inter-channel phase offset of -3600 to +3600 with 0.0010 resolution
- 1mHz to up to 100MHz Pulse generation with 100ps width resolution, <,30ps jitter, and independently variable rise/fall times
- Wideband noise generator with up to 100MHz noise bandwidth
- Wide range of standard and arbitrary waveforms built-in
- Arbitrary waveforms of 14-bits / 400MSa/s (TGF4042 & TGF4082) or 16-bits / 800MSa/s (TGF4162 & TGF4242)
- Waveform Manager Plus for Windows, editing software included
- Front USB host socket for waveform storage and file transfers using Flash drives
- Modulation frequencies up to 10MHz internal and 5MHz external
- Gate and Burst modes with internal and external triggering
Specifications:
- No. of channels: 2
- Frequency range: 1µHz to 40MHz
- Frequency resolution: 1µHz, 14 digits
- Max frequency (sine): 40 Mhz
- Max frequency (square/ pulse): 25 Mhz
- Vertical bits / Sample rate: 14 bits / 400Msa/s
- Noise bandwidth: 50 Mhz
The TGF4042 is a 40 MHz function generator. The TGF4000 series is the latest function/arbitrary generator series from Aim-TTi offering class-leading performance and unrivalled value for money.
Технические характеристики
| Manufacturer | Thurlby Thandar Instruments |
|---|---|
| Condition | New |
| Frequency | 40 MHz |
