The LoRa TEMP+ T4 is a temperature sensor specially designed for monitoring hot water systems. It measures and records the temperature inside the pipes via an external temperature sensor and attaches to the pipes with cable ties without damage them. In case of thresholds excursions, real-time alerts are sent by SMS text message, mail or voice message. The LoRa TEMP+ T4 connects to the LoRaWAN network of telecom operators members of the LoRa Alliance or to the private network of a JRI Gateway for transferring data to the JRI-MySirius monitoring platform. Data can be viewed and managed via the easy-to-use and intuitive web based JRI-MySirius interface. BENEFITS — Measure, record, and send out alert notifications spontaneously — Mounting hole & mounting bracket for easy installation — Dedicated to hot water systems — User-replaceable long lasting battery — 868MHz / 915MHz TECHNICAL FEATURES Temperature range : -40°C to +85°C Measurement accuracy : ±0.3°C on a copper pipe ±0.5°C on a CPVC pipe Communication frequency : 868/915 MHz Memory : 10 000 data points Radio range : Up to 16 km open field range Interface : 1 LED, 1 push button Sensor : External PT100 Dimensions : 65 x 65 x 28 mm Weight : 100 g Power supply : A size replaceable lithium battery Battery lifetime : 5 years (logging interval: 15min, transmission interval: 60min)
Технические характеристики
CharacteristicsMeasured quantitytemperatureConnector typeradio frequencySensor typePt100Displaywithout displayApplicationsfor monitoringOther characteristicswith external sensorMemory capacity
10,000 unit
