Additional Features:
- 15 ADC + Peak AC Maximum Current Capability
- 50 A Peak Pulse Current Capability
- Connects Directly to Oscilloscopes with the TekProbe™ Interface
- Provides Automatic Units Scaling and Readout on the Oscilloscope Display
- Degauss Button and Thumbwheel for DC Offset Adjustment
- Easy-to-Use and Accurate AC/DC Current Measurements
- DC to >,50 MHz Bandwidth
- Core Jaw Diameter of 5 mm (0.2 in.)
- Accurately Measures Current Levels as Low as 10 mA per Division
- High Accuracy with Typically Less than 1% DC Gain Error
- Split-core Construction allows Easy Circuit Connection
- Low Noise and DC Drift
- Safety Certified
- Includes: Instruction Manual (English), Probe Ground Lead – 6 in. length, Nylon Carrying Case
- Standard Warranty: One-year parts and labor
Applications:
- Power Supplies
- Semiconductor Devices
- Power Inverter/Converters
- Electronic Ballasts
- Industrial/Consumer Electronics
- Mobile Communications
- Motor Drives
- Transportation Systems
The TCP202A is from a family of high-performance, easy-to-use AC/DC current probes designed for use with a variety of oscilloscopes. The TCP202A is designed for direct connection to oscilloscopes with the TekProbe™ probe interface.
These AC/DC current probes provide sufficient performance to support 50 MHz measurement system bandwidth. The TCP202A provides a maximum 15 ADC + Peak AC measurement range. These probes also provide excellent accuracy to current levels as low as 10 mA, important for meeting today’s challenging current measurement needs.
Технические характеристики
| Manufacturer | Tektronix |
|---|---|
| Condition | New |
| Amps | 15 A |
| Frequency | 50 MHz |
