It’s applicable for concrete cast in situ pile for foundation construction such as urban construction,railway,highway,bridge,subway and building. Hydraulic telescopic (TDP series) track chassis and large diameter of slewing bearing which is special for rotary drilling rig is used, and meets super strong stability and convenience of transportation. Single row of rope and master winch is used to solve effectively the wear issue of steel wire rope and increase effectively the service life of steel wire rope, and the master winch is provided with drilling depth detector, and the single row of rope makes the depth detection more accurate. Anti-noise cab with FOPS function, adjustable seat, air conditioner, interior and exterior lights, windshield wiper with water spray function. Control console with various instruments and handles, color LCD with powerful function.
Технические характеристики
CharacteristicsFunctionsoil investigation, deep-stabilizationApplicationsmultifunction, piling, deepMobilitycrawlerDrilling unitrotaryOther characteristicshydraulic, construction, diesel engineDrilling diameter
1,800 mm (71 in)
Drilling depth
60 m (19610)
Overall length (working)
8,350 mm (329 in)
Overall width (working)
4,200 mm (165 in)
Overall heigth (working)
20,480 mm (806 in)
Machine weight
60 t (66.1 us ton)
Motor power
194 kW (263.77 hp)
Hydraulic working pressure
35 MPa
Max driving speed
2 km/h (1 mph)
Overall length (when moving)
14,380 mm (566 in)
Overall width (when moving)
3,000 mm (118 in)
Overall height (when moving)
3,490 mm (137 in)
