The sliding gate motor valve type 8038 in reinforced design with high-resolution fast actuatoris suitable for a wide range of process applications. Media such as steam, liquids, gases, etc. can be handled precisely. The interaction of high-precision control electronics with the precise stepper motor results in a positioning accuracy of ± 0.2% even with a valve stroke of only 6 mm. By means of super-capacitor technology, in the event of a power supply failure, the valve returns to its defined basic position. •Size: DN 15 — DN 250 •Pressure: PN 10/40, PN100 ANSI #150, #300, #600 •Material: Stainless steel: Body 1.4408 Cover 1.4404 Carbon steel: Body 1.0619 Cover 1.4404 Alloy C276 •Temperature: Media temperature: -60° C up to 350 °C Special versions available on request. Connection: Wafer type design Accessories: Metal bellows Position electronics Analog stroke feedback Limit switch Fail safe feature Actuator: Control actuators or 3-point actuators Thrust: 2kN, 5kN Voltage: 100 — 240V (50Hz / 60Hz) or 24V AC/DC Class of protection: IP 67
Технические характеристики
CharacteristicsTypesliding gateOperationelectrically-operatedFunctionshut-off, regulatingMediafor hot water, for cooling water, for gas, for air, for steam, for oxygen, for natural gas, for CO2, propaneBodywafer, stainless steel, carbon steelApplicationsfor industrial applications, for the chemical industry, for the food industry, for wafersOther characteristicsrugged, for aggressive mediaDN
Max.: 250 mm (9.843 in)
Min.: 15 mm (0.591 in)
Pressure
Max.: 100 bar (1,450.4 psi)
Min.: 10 bar (145 psi)
Temperature
Max.: 350 °C (662 °F)
Min.: -60 °C (-76 °F)
