Description
Head
- 9.7 in. touchscreen retina display
- 5MP color CMOS camera
- 4 USB ports for attaching keyboard, mouse, storage device or remote capture button
- SeBaAccess technology allows for individual log in, via an access card swipped in front of the Seba label
- SeBaShare cloud based storage allows simple uploading of images to unique account on the cloud for accessing of images anywhere (log in based off from SeBaAccess)
- Capture still or video images and save them to SeBaShare or USB storage device
- Capture, review, measure, and annotate images
- Single power source controls power to the camera, computer and microscope
Objectives
- Sealed 40X to prevent accidental damage from use of oil at 100X
- Infinity corrected
- Parfocal and parcentered
Stand
- Built-in carrying handle
- Reverse objective turret (4 position) allows for easy access to slides
- Adjustable focusing stop protects slides from accidental damage
- Removable LED cartridge
Illumination
- Full Koehler illumination with field diaphragm
- 50,000 bulb life
Cool, stable, color temperature and brightness intensity
Certifications
Quality Performance Certification
Технические характеристики
| Condenser Type | N.A. 1.25 Abbe Achromatic condenser with Iris diaphragm and filter holder |
| Camera Type | 5MP CMOS, 2.2andmu,m pixels |
| Eyepiece | 20 mm FOV |
| Lighting Type | LED 3w |
| Resolution | Coarse and Fine |
| Nosepiece | Reversed Quadruple Nosepiece |
| Software Type | Capture still images and video, Upload to SeBaShare |
| Width (English) | 9.6 in. |
| Electrical Requirements | External, 110/220 V Auto Switch 12 V, DC Supply |
