DCEM-2 DC energy meter is an advanced solution for two channels metering in DC system. It can visually display voltage, current, power data and bidirectional energy cumulative data. With a panel keypad, it can set voltage display parameters and the hall CT parameters. With RS485 communication interface, DCEM-2 can be connected to the monitoring center. The current and voltage loops both isolated, suitable for monitoring of incoming/output lines of solar system or UPS battery system. Current — 0.000 ~ 500A, Depends on the shunt, standard ../75mV Voltage — 0.0 ~ 1000V Active power — 0.000 ~ 9999KW Energy — 0.00Wh ~ 999999999Wh Optional 1 channel DO and 4 channels DI
Технические характеристики
CharacteristicsTypesingle-phaseAssemblyDIN railOther characteristicsRS-485, Modbus, digital, programmable, smart, multi-function, with built-in communicationVoltage
400 V
Max.: 600 V
Min.: 0 V
Primary current
100 A
Max.: 9,999 A
Min.: 0 A
