Sick TTK70-HXA0-K02
Datasheet:
- Article: 1037434
- Supply set: Magnetic tape not included
- Measuring step: 0.244 µm when interpolating sine and cosine signals, for example 12 bits
- Measurement length: 3.920 mm
- Resolution: 1 µm
- Period length: 1 mm
- Traveling speed: 10 m/s
possible reliable alignment of absolute position, 1.3 m/s - Reproduction accuracy:
- System accuracy: ± 10 µm (+20 °C)
- Difference between the results of measuring one parameter during the forward and reverse stroke of the measuring element:
- Communication interface: HIPERFACE®
- Code type: Binary
- Available memory area: 1.792 Byte (E²PROM 2048)
- Supply voltage: 7 V DC … 12 V DC
- Recommended supply voltage: 8 V DC
- Operating current: 65 mA (no load)
- Connection type: Connector, M12, 8-pin
- Dimensions: cm Dimensional drawing
- Supply contents: Magnetic tape not included
- Weight: 0.08 kg
- Material, reading head: Zinc die casting
- EMC: According to EN 61000-6-2 and EN 61000-6-3
- Protection type: IP67, with mating plug installed (according to IEC 60529)
- Operating temperature range: –30 °C … +80 °C
- Storage temperature range: –40 °C … +85 °C, unpacked
- Permissible relative air humidity: 100%, condensation allowed
- Shock resistance: 30 g, 6 ms (EN 60068-2-27)
- Vibration resistance: 20 g, 10 Hz … 2.000 Hz (EN 60068-2-6)
- Permissible maximum ambient field strength:
- Permissible maximum field strength:
- Category:Linear encoders with scale
- Series:TTK70
