Штангенциркуль Mitutoyo ABSOLUTE Digimatic Low Force специально разработан для точного измерения деталей из более мягких материалов, таких как пластик или резина. Измерения отображаются на цифровом ЖК-дисплее с выходом SPC для удобной автоматической записи.
Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.
Оплата физическими и юридическими лицами безналичным расчетом.
The Mitutoyo ABSOLUTE Digimatic Low Force caliper uses a low measuring force to take highly accurate measurements of resilient workpieces that standard calipers cannot measure. The lower measuring force greatly reduces the compression of materials such as elastic, plastic and rubber, providing a more precise, repeatable measurement. A consistently low measuring force is guaranteed by only taking measurements when the pointer on the caliper is between two fiducial lines.
Available in Metric and Inch/Metric models
Measures pieces that standard calipers cannot measure
Range is 0-180mm/0-7” with accuracy rated at +/- 0.05mm
SPC output function offers quick and easy data management in real time
ABSOLUTE (ABS) linear scale eliminates the need for setting the origin point every time the micrometer is powered on, overspeed errors are also eliminated
Functions include Origin Set, Zero Setting, Power On/Off, Data Output and inch/mm conversion (on inch/metric models only)
Alarm: Low Voltage, Counting Value Composition Error
Constructed of hardened stainless steel for better durability and longevity
Supplied in fitted plastic case
Order No.:
Product Image:
Units:
Range:
Resolution:
Accuracy:
Order No.:
573-191-30
Metric
0-180mm
0.01mm
±0.05mm
573-291-30
Metric, Inch
0-180mm / 0-7″
0.01mm / 0.0005″
±0.002″
573-191-30
573-291-30
Технические характеристики
Technology:
Digimatic
Length Standard:
ABSOLUTE electromagnetic induction type linear encoder
