Low capacity hybrid motor connection cable with overall copper screen 0.6/1 kV Marking for SL 875 C 08750105: SAB BRÖCKSKES · D-VIERSEN · 08750105 SL 875 C 4 x 1,5 mm2 (1000V) + (2 x 1,0 mm2) (1000V) + (2 x AWG 22) (1000V)C · DESINA UL AWM Style 20910 80°C CSA AWM I/II A/B 80°C 300V FT1 FT2 CE Hybrid motor connection cable with overall copper screen 0.6/1 kV for use as all-in-one cable solution in motor feedback systems. This hybrid cable with CSA approval is UL recognized and is suitable for cable tracks. used as all-in-one cable solution in motor feedback systems low capacity construction UL recognized, CSA approval very good EMC characteristics long service life adhesion-free installation suitable for cable tracks halogen-free PWIS uncritical (PWIS= paint-wetting impairment substances) flexible at low temperatures DESINA® colours Cable harnessing possible on request!
Технические характеристики
CharacteristicsTypehybridFormatDINProtectioninsulated, flame-retardant, oil-resistant, chemical-resistant, with copper screen, self-extinguishing, weather-resistantConfigurationmulti-strandCore materialcopperApplicationsfor electric motors, for servo motorsOther characteristicsflexible, halogen-free, connection, UL, UL/CSANominal voltage
1 V, 500 V, 600 V, 3,000 V, 4,000 V
Temperature
Min.: -50 °C (-58 °F)
Max.: 90 °C (194 °F)
Cross-section
Min.: 0.5 mm² (0 in²)
Max.: 16 mm² (0.02 in²)
