The 66142 Hg(Xe) Arc Lamp is 500 watt and has a 2.5 x 3.0 mm effective arc size. Strong mercury lines through the visible and ultraviolet dominate the output spectrum of these lamps. A continuum in the infrared persists to 2.5 &mu,m and beyond.
Технические характеристики
- Type Mercury-Xenon Lamp
- Lamp Type Hg(Xe)
- Lamp Wattage 500 W
- Average life 600 h
- Bulb Diameter 29 mm
- Effective Arc Size 2.5 x 3.0 mm
- Horizontal Intensity 13000 cd
- Approximate Brightness 500 cd mm-2
- Approximate Flux 13000 lm
- Lamp Current 19 A
- Lamp Voltage 26 V
