The 0.75 inch (19.05 mm) 9317-K Adjustment Screw provides smooth, wobble-free adjustment combined with exceptional long-term stability and low susceptibility to thermal variation. It is the same 1/4-80 precision screw used in our optic mounts and allows you to build your own mounts or positioners. In addition to a travel of 0.75 inch (19.05 mm), the screw has a ball tip, unbraked brass bushing, and is Hex-key adjusted.
Технические характеристики
- Travel Range 19.1 mm
- Adjustment Screw Thread 1/4-80
- Drive Type Hex
- Axial Load Capacity 90 N
- Lock No Lock
- Tip Style Ball
- Sensitivity 0.88 m
