The AJS254-0.5K-NL Ultra-fine Adjustment Screw has precision cut threads for exceptionally smooth adjustment and much higher sensitivity than standard micrometers. The ultra-fine pitch, knob adjusted, AJS254-0.5K-NL screw offers 0.5 inch (12.7 mm) precision travel. This ultra-fine adjustment is ideal for use with Newport optical mounts, stages, and most micrometer-compatible components. With much better than sub-micron sensitivity (280 nm), they are a cost-effective alternative to micrometers where position readout is not required.
Технические характеристики
- Travel Range 12.7 mm
- Adjustment Screw Thread 1/4-254
- Drive Type Knob
- Axial Load Capacity 90 N
- Lock No Lock
- Tip Style Ball
- Sensitivity 0.28 m
- Weight 25 g
