The SNV-20F laser is part of the more advanced generations of Microchip Series designed for long life UV emiussion. This laser first produces 1064nm pulses which are directly generated from the diode pumped passively Q-switched Nd:YAG microchip engine. A third harmonic generation stage produces the 355 nm radiation with a very good beam quality and lifetime. Microchip lasers are also easy to operate and service, controllers can be used with every laser head model and swapped within minutes while keeping constant operating parameters. KEY FEATURES > Family: MicroChip > Energy/Pulse: 0.5 µJ > Repetition rate: 19 kHz > Triggered: no > Single frequency: yes > Linewidth: 0.3 pm > Pulse duration: 600 ps > Package: SNxII
Технические характеристики
CharacteristicsOperational modeQ-switchedTechnology solid-stateSpectrumUVApplicationsfor micro-machining, for semiconductors, markingOther characteristicsair-cooled, Nd:YAGPower
0.01 W, 700 W
Wavelength
355 nm
