RTD, TC, mV signal transmitter, DIN/B or DIN rail head mounting -With 3 customizable linearizations (up to 96 segments) -Reversible output (e.g. 20 to 4 mA) -Programmable retransmission range -Isolated version available Configurable from: – “Windows” PC with RF programmer (AFC1 programming kit + ATNFC-soft program) or – Android smartphone with NFC and ATNFC APP (free) DIMENSIONS — Ø 45 x 23 mm INPUTS — RTD (Pt100, Pt 1000, Ni100), TC (B, E, J, K, N, R, S, T), mV (-10… +70 mV) Potentiometer (10… 400Ω / 10… 4kΩ) OUTPUTS — 4… 20 mA OVERALL ACCURACY — Better than 0.2% f.s. OPERATING TEMPERATURE — -40… +85°C CONFORMITY — CE, EN 61326-1 Calibration according to EN 60584-1: 2013, EN60751: 2008
Технические характеристики
CharacteristicsMountingprobe head-mounted, DIN rail mountInput typeRTD, thermocoupleOutput signal4-20 mAOther characteristicsprogrammable, insulatedApplicationsprocess
