Drawing number 3242-20 Dimension bolting M20 x 105 (130) Alternativ floor bolting M16 Spacing washer to push-in cam see accessories Fine adjusting range 10 mm Maximum adjustment load 120 kN Maximum torque 72 Nm Torque per 10 kN 6 Nm Hexagonal Allen key for adjustment 17 mm Height adjustment per adjusting screw turn 0,546 mm Vibration protection, nitril vulcanised on 20 mm 80° Shore Weight of wedge 11,0 kg
Технические характеристики
CharacteristicsApplicationsprecisionOther characteristicsadjustable, with screw on bolt
