Drawing number 3241-01 Dimension floor bolting M20 x 100 (125) Kind of floor bolting screw on bolt Alternativ floor bolting M16 Spacing washer to push-in cam see accessories Fine adjusting range 10 mm Maximum adjustment load 120 kN Maximum torque 72 Nm Torque per 10 kN 6 Nm Hexagonal wrench for adjustment 17 mm Height adjustment per adjusting screw turn 0,546 mm Flexibility/rigidity 5000 N/µm Weight of wedge 6,8 kg
Технические характеристики
CharacteristicsApplicationsprecisionOther characteristicsadjustable, with screw on bolt
